19.05MM SA179 Boiler Tube ASME SA179 for Stripper Feed Bottom Exchanger

Product Details:

Place of Origin:	China, Korea, UE
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2015
Model Number:	ASME SA179

Payment & Shipping Terms:

Minimum Order Quantity:	1000 KGS
Price:	Negotiable
Packaging Details:	Ply-Wooden Case /Iron Case/ Bundle with Plastic Cap
Delivery Time:	15 - 60 Work Days
Payment Terms:	T/T, L/C at sight
Supply Ability:	15000 Tons Per Year

Contact Now

All Products

Stainless Steel Seamless Pipe (274)

Stainless Steel Seamless Tube (263)

Duplex Stainless Steel Pipe (125)

Duplex Stainless Steel Tube (22)

Needle Tube (69)

Fin Tube (568)

Heat Exchanger (8)

Heat Exchanger Tube (414)

Heat Exchanger Tube Bundle (34)

Heat Exchanger Tubesheet (116)

Heat Exchanger Baffle (35)

Air Cooler (3)

Pressure Vessel (1)

Stainless Steel Welded Pipe (56)

Stainless Steel Welded Tube (110)

Nickel Alloy Pipe (263)

Nickel Alloy Tube (61)

Copper Alloy Tube (205)

Alloy Steel Tube (173)

Titanium Tube (6)

Bright Annealed Tube (155)

Boiler Tube (135)

Steel Fitting (773)

Steel Flange (566)

Others (382)

U Bend Tube (0)

Detailed Product Description

Standard:	ASME SA179	Material Grade:	SA179
Type:	Seamless	Product Name:	Carbon Steel Tube
O.D. Size:	19.05mm	Wall Thickness:	1.5mm
Ends:	Plain End	Applications:	Stripper Feed Bottom Exchanger
Highlight:	Heat Exchanger Boiler Tube
Highlight:	Stripper Feed Bottom Exchanger Boiler Tube , ASME SA179 Boiler Tube , 19.05MM Boiler Tube

19.05MM SA179 Boiler Tube ASME SA179 for Stripper Feed Bottom Exchanger

Yuhong Holding Group Co., Ltd. is a world-renowned manufacturer and exporter of high-quality heat exchanger tubes and industrial equipment. With over 20 years of export experience and a presence in 80 countries, we rank among the top five exporters of heat exchanger tubes in China. Our facility spans 20,000 m², housing 55 advanced production lines and over 110 skilled employees. We pride ourselves on delivering superior product quality and outstanding service to meet the needs of our global clients.

One of our signature products is the SA179 Boiler Tube, a key component for heat exchangers, including applications in Stripper Feed Bottom Exchangers. Below, we provide an in-depth overview of the material, dimensions, and applications.

Material: SA179 Carbon Steel

SA179 is a specification for seamless, low-carbon steel tubes with exceptional thermal conductivity and mechanical properties, making it ideal for heat exchanger and boiler applications.

Property Description

Material Grade ASME SA179 / ASTM A179

Type Seamless Low-Carbon Steel Tube

Standard ASME Boiler and Pressure Vessel Code

Chemical Composition C ≤ 0.06%, Mn 0.27%-0.63%, P ≤ 0.035%, S ≤ 0.035%

Mechanical Properties Tensile Strength ≥ 325 MPa, Yield Strength ≥ 180 MPa, Elongation ≥ 35%

Common Sizes of SA179 Tubes

Our SA179 boiler tubes are available in various dimensions to meet diverse industrial requirements. Below are the standard sizes we offer:

Outer Diameter (OD) Wall Thickness Length (Customizable)
19.05 mm (¾") 2.0 mm - 4.0 mm Up to 12 meters
25.4 mm (1") 2.5 mm - 5.0 mm According to customer requirements
38.1 mm (1.5") 3.0 mm - 5.5 mm Single random or double random

We also offer customized sizes based on specific client needs.

Applications of SA179 Boiler Tubes

SA179 seamless tubes are widely used in heat exchangers, condensers, and boiler systems due to their outstanding thermal conductivity and durability. Common applications include:

Stripper Feed Bottom Exchangers:

In stripper feed systems, these exchangers are essential for efficiently transferring heat and maintaining process stability during the separation of lighter and heavier components in chemical plants. SA179 tubes ensure consistent performance under high-pressure and high-temperature conditions.

Boiler Systems:

Used in economizers, superheaters, and air preheaters for power generation and industrial boilers.

Heat Exchangers & Condensers:

Ideal for petrochemical, refinery, and power plant operations.

Chemical and Petrochemical Processing:

Suitable for heat recovery systems and process heating applications.

An Overview of Stripper Feed Bottom Exchanger

Stripper feed bottom exchangers play a critical role in chemical processing and refining. These exchangers are designed to handle high-temperature and high-pressure environments, transferring heat between feed streams and the bottom product. By using SA179 boiler tubes, these exchangers achieve higher efficiency, thermal stability, and durability, making them an essential component in optimizing industrial operations.

Why Choose Yuhong Holding Group Co., Ltd?

With over two decades of experience, Yuhong Holding Group Co., Ltd. continues to lead the industry in heat exchanger tubing solutions. Our advanced manufacturing capabilities, skilled workforce, and commitment to quality ensure that our products meet the highest standards. As a trusted partner to clients in over 80 countries, we specialize in delivering reliable and cost-effective solutions tailored to your needs.

For inquiries or more information about our SA179 Boiler Tubes, contact us today. Yuhong Holding Group Co., Ltd. is ready to assist with your industrial tubing requirements.
