Copper Nickel Boiler Seamless Tube ASTM B111 ASME SB111 C71640 CW353H

Product Details:

Place of Origin:	CHINA
Brand Name:	YUHONG
Certification:	ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008
Model Number:	66-30-2-2 Cu-Ni ,C71640, CW353H

Payment & Shipping Terms:

Minimum Order Quantity:	100KGS
Packaging Details:	PLYWOOD CASE,BUNDLE,PALLET
Delivery Time:	7DAYS
Payment Terms:	L/C, T/T

Contact Now

All Products

Stainless Steel Seamless Pipe (274)

Stainless Steel Seamless Tube (263)

Duplex Stainless Steel Pipe (125)

Duplex Stainless Steel Tube (22)

Needle Tube (69)

Fin Tube (568)

Heat Exchanger (8)

Heat Exchanger Tube (414)

Heat Exchanger Tube Bundle (34)

Heat Exchanger Tubesheet (116)

Heat Exchanger Baffle (35)

Air Cooler (3)

Pressure Vessel (1)

Stainless Steel Welded Pipe (56)

Stainless Steel Welded Tube (110)

Nickel Alloy Pipe (263)

Nickel Alloy Tube (61)

Copper Alloy Tube (205)

Alloy Steel Tube (173)

Titanium Tube (6)

Bright Annealed Tube (155)

Boiler Tube (135)

Steel Fitting (773)

Steel Flange (566)

Others (382)

U Bend Tube (0)

Detailed Product Description

MATERIAL:	66-30-2-2 Cu-Ni ,C71640, CW353H	STANDARD:	ASTM B111
NAME:	Seamless Tube, Welded Tube , Copper Fitting , Copper Fin Tube	OD:	12.7MM,19.05MM,25.4MM....
WT:	0.89MM,1.2MM,1.5MM...	STATUS:	O61
Highlight:	ASTM B111 Copper Nickel Boiler Tube , Seamless Copper Nickel Boiler Tube , ASME SB111 Copper Nickel Boiler Tube

Copper Nickel Boiler Seamless Tube ASTM B111 ASME SB111 C71640 CW353H

The material C71640 is a type of copper alloy, specifically categorized under bronze alloys. It is known for its high strength and corrosion resistance, particularly in marine environments.The alloy is sometimes called a nickel bronze because of the substantial nickel content. The material is prized for its durability and is often used in applications where both strength and resistance to corrosion are critical.

Key Properties of C71640 Copper Alloy:

Composition: Typically consists of copper (Cu) with a significant amount of nickel (Ni), and small amounts of other elements such as tin (Sn) and iron (Fe).
Nickel Content: C71640 typically contains around 6% nickel, which gives it enhanced strength and resistance to corrosion, especially in seawater.
Applications: It is commonly used in marine hardware, valves, pump components, and marine engineering due to its excellent corrosion resistance, especially in saltwater environments.

Material Composition:

Designation	Chemical Composition %
Designation	Cu	Sn	Al	As	Ni	Fe	Mn	Pb max.	Zn
C70400	Rem	–	–	–	4.8-6.2	1.3-1.7	0.3-0.8	0.05	1.0max
C70600	Rem	–	–	–	9.0-11.0	1.0-1.8	1.0max	0.05	1.0max
C71500	Rem	–	–	–	29.0-33.0	0.4-1.0	1.0max	0.05	1.0max
C71640	Rem	–	–	–	29.0-32.0	1.7-2.3	1.5-2.5	0.05	1.0max

Properties:

- Corrosion Resistance: Excellent performance in marine/saline environments, resisting biofouling and erosion.

- Thermal Conductivity: Suitable for heat exchangers, condensers, and desalination systems.

- Mechanical Strength: Durable under high-stress conditions, often cold-worked or annealed for specific applications.

Standards & Applications:

- ASTM/ASME Standards: ASTM B111 (Standard Specification for Copper-Nickel Alloy Tubes for Condensers and Heat Exchangers).

Common Uses:

- Marine engineering (ship piping, offshore platforms).

- Power plant condensers.

- Desalination and chemical processing equipment.

Copper Nickel Boiler Seamless Tube ASTM B111 ASME SB111 C71640 CW353H 0
